| Frequency Range: 10.0MHz to 30.0MHz |
| Input Voltage: +2.8V, +3.3V±5% or +5.0VDC ±5% |
| Control Voltage Centre: +2.5 VDC |
| Initial Frequency Accuracy: ±15ppm with Conrol V at +2.5VDC |
| Control Voltage Range: +0.5V to +4.5VDC |
| Frequency Deviation Range: ±50ppm typical* |
| Output Wave Form: True Sine Wave |
| Output Level: 10kW//10pF load, 1.0V p-p |
| Harmonics: <-25dBc |
| Phase Noise: -130dBc/Hz at 1kHz offset |
| Current Consumption Supply = 2.8V: 1.0mA Supply = 3.3V: 1.1mA Supply = 5.0V: 1.2mA |
| Start-up Time: 2.0ms typical |
| Storage Temperature: -50° to +125°C |
| Sub-Harmonics: None |
| Ageing: ±5ppm per year maximum |
| Enable/Disable: Not implemented - 4 pad package |
| RoHS Status: Fully compliant |
