Features
Typical Applications
Specifications
| Frequency: 32.7680kHz |
| Frequency stability* -10° to +60°C: +30ppm to -60ppm +25°C: +30ppm to 0ppm (Vdd 2.0V to 6.0V) |
| Temperature Range: -10° to +60°C (Operating) |
| Input Voltage: +1.5 Volts to 6.0 Volts |
| Input Current: 5 micro Amps (at +3.3V supply) |
| Output: HCMOS |
| Output Load: 15pF |
| Rise and Fall Times: 200ns max. |
| Start-up Time: 500ms max. (3.3 Volts supply at 25°C) |
